Cleco Pneumatic General Accessories

Cleco TVP-100 Series Torque Verifiers verify fastener installation with OK/NOK audio and visual indicators. Cleco TVP-100 Series Torque Verifiers feature on screen verification of individual fastener assembly status with batch count, the VGA screen displays a graph for each rundown, and stores 1,000 rundowns. Cleco TVP-100 Series Torque Verifiers also feature sequencing capabilities, multiple languages, password protection, the “Auto Cal” permits fast and easy tool set up for any joint type, and 8 parameter sets are available for multiple applications.

The Cleco TVP-100 Series Torque Verifier provides low-cost assembly assurance for screwdrivers, nutrunners and pulse tools. The Cleco TVP-100 verifier improves your assembly process by eliminating operator error caused by early trigger release, fastener cross-threading or re-hits.The Cleco TVP-100 is designed for use with clutch screwdrivers/nutrunners and Cleco shut-off pulse tools equipped with torque signal kits.

The Cleco TVP-100 provides visual and audio feedback for both individual fastener and batch parameters, assuring that every fastener has been rundown to the capability of the tool. Based on existing Cleco TME controller technology, the Cleco TVP-100 navigational screen allows for simple set-up and operation. The Cleco TVP-100 works by reading the signature of a ported assembly tool through its fastening cycle. Any deviation from the normal signature caused by re-hits, cross threads, early trigger release or a number of variables will elicit a NOK visual and audio signal from the verifier, notifying the operator of an error. Whereas a Cleco DC controller controls the tool and the fastening process, the TVP-100 is a cost-effective way of verifying torque by following the torque signature of a tool.

Cleco balance arms are engineered to deliver longer service life using durable components, rugged design and operator-sensitive features. These arms absorb the torque produced by the screwdriver, eliminating torque reaction to the operator. Balanced by springs or air cylinders, the arm and not the operator supports the weight of the tool. By reducing the fatigue factors, the operator productivity is improved. Tool movement and placement over the fastener is virtually effortless since most moving parts of the balance arm are mounted on ball bearings. Access to the tool is easily changeable by adjusting the springs or cylinder supporting the forearm.

Arm components and materials are selected for strength and rigidity. Precision aluminum sand castings used in the articulating arm section are light but sturdy. Over 25 models of the Cleco screwdriver balance arms are available. Air cylinder models are capable of supporting tools weighing up to 10 lbs. (4.5 kg.). Spring models will support tools weighing up to 5 lbs. (2.3 kg.). Both styles have torque capacities of 10 ft. lbs. (13.5 Nm). Arms can be post mounted, wall mounted or mounted on an adjustable height post. Tool holders for all models will accommodate most major brands of air tools…straight and pistol.
